耐用性好
1800 系列能够抵御恶劣的环境，充当您坚实的后盾。
保养简便
花在修复工具上的时间减少，因此您能够将更多时间用在生产中。
| Model | Max. Power (hp) | Max. Power (kw) | Reversible | Torque Stall (ft-lb) | Torque Stall (Nm) | Free Speed (rpm) | Torque Output @ Max. H.P. (ft-lb) | Torque Output @ Max. H.P. (Nm) | Speed at Max. Power (rpm) | Starting Torque (ft-lb) | Starting Torque (Nm) | Air Consumption at Max. Power (scfm) | Air Consumption at Max. Power (m^3/m) | Weight (lb) | Weight (kg) | Length (in) | Length (mm) | Diameter/Width (in) | Diameter/Width (mm) | In Line Motor |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1801N | 1.4 | 1.04 | No | 14 | 19 | 1990 | 7 | 9.49 | 995 | 10.5 | 14.2 | 46 | 1.3 | 5.375 | 2.44 | 6.94 | 176.2 | 2.81 | 71.4 | Yes |
| 1801P | 1.35 | 1.01 | No | 23 | 31.2 | 1050 | 11.5 | 15.59 | 525 | 17.2 | 23.3 | 46 | 1.3 | 5.75 | 2.61 | 6.94 | 176.2 | 2.81 | 71.4 | Yes |
| 1801Q | 1.35 | 1.01 | No | 40 | 54.2 | 650 | 20 | 27.12 | 325 | 30 | 40.7 | 46 | 1.3 | 5.75 | 2.61 | 8.31 | 211.1 | 2.81 | 71.4 | Yes |
| 1801U | 1.35 | 1.01 | No | 55 | 74.6 | 435 | 27.5 | 37.28 | 217.5 | 41 | 55.6 | 46 | 1.3 | 5.75 | 2.61 | 8.31 | 211.1 | 2.81 | 71.4 | Yes |
| 1801W | 1.35 | 1.01 | No | 70 | 94.9 | 370 | 35 | 47.45 | 185 | 52 | 70.5 | 46 | 1.3 | 5.75 | 2.61 | 8.31 | 211.1 | 2.81 | 71.4 | Yes |
| 1841N | 1.2 | 0.89 | Yes | 12.5 | 17 | 1700 | 6.25 | 8.47 | 850 | 9.3 | 12.6 | 43 | 1.22 | 5.5 | 2.5 | 8.31 | 211.1 | 2.81 | 71.4 | Yes |
| 1841P | 1.1 | 0.82 | Yes | 20 | 27.1 | 900 | 10 | 13.56 | 450 | 15 | 20.3 | 43 | 1.22 | 5.875 | 2.67 | 8.31 | 211.1 | 2.81 | 71.4 | Yes |
| 1841Q | 1.1 | 0.82 | Yes | 36 | 48.8 | 550 | 18 | 24.4 | 275 | 27 | 36.6 | 43 | 1.22 | 5.875 | 2.67 | 8.31 | 211.1 | 2.81 | 71.4 | Yes |
| 1841U | 1.1 | 0.82 | Yes | 50 | 67.8 | 380 | 25 | 33.9 | 190 | 37 | 50.2 | 43 | 1.22 | 5.875 | 2.67 | 8.31 | 211.1 | 2.81 | 71.4 | Yes |
| 1841W | 1.1 | 0.82 | Yes | 60 | 81.4 | 320 | 30 | 40.67 | 160 | 45 | 61 | 43 | 1.22 | 5.875 | 2.67 | 8.31 | 211.1 | 2.81 | 71.4 | Yes |
