耐用性好
92 系列能够抵御恶劣环境，极其适合高扭矩和增强侧面负载应用。
保养简便
得益于简便的保养，您够将时间集中在工作上，而不必过度关注工具。
详细参数
| Model | Max. Power (hp) | Max. Power (kw) | Reversible | Torque Stall (ft-lb) | Torque Stall (Nm) | Free Speed (rpm) | Torque Output @ Max. H.P. (ft-lb) | Torque Output @ Max. H.P. (Nm) | Speed at Max. Power (rpm) | Starting Torque (ft-lb) | Starting Torque (Nm) | Air Consumption at Max. Power (scfm) | Air Consumption at Max. Power (m^3/m) | Weight (lb) | Weight (kg) | Length (in) | Length (mm) | Diameter/Width (in) | Diameter/Width (mm) | In Line Motor |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 92RA005 | 8.15 | 6.08 | Yes | 75 | 102 | 1390 | 37.5 | 50.84 | 910 | 56 | 75.9 | 230 | 6.51 | 46 | 20.9 | 15.22 | 386.6 | 10.5 | 266.7 | No |
| 92RA008 | 8.15 | 6.08 | Yes | 109 | 148 | 1296 | 54.5 | 73.89 | 620 | 80 | 109 | 230 | 6.51 | 46 | 20.9 | 15.22 | 386.6 | 10.5 | 266.7 | No |
| 92RA011 | 8.15 | 6.08 | Yes | 164.5 | 223 | 852 | 82.25 | 111.52 | 415 | 120 | 163 | 230 | 6.51 | 46 | 20.9 | 15.22 | 386.6 | 10.5 | 266.7 | No |
| 92RA014 | 8.15 | 6.08 | Yes | 208 | 282 | 682 | 104 | 141.01 | 327 | 152 | 206 | 230 | 6.51 | 46 | 20.9 | 15.22 | 386.6 | 10.5 | 266.7 | No |
| 92RA017 | 8.15 | 6.08 | Yes | 248 | 336 | 571 | 124 | 168.12 | 274 | 180 | 244 | 230 | 6.51 | 46 | 20.9 | 15.22 | 386.6 | 10.5 | 266.7 | No |
| 92RA022 | 8.15 | 6.08 | Yes | 326 | 442 | 435 | 163 | 221 | 209 | 235 | 319 | 230 | 6.51 | 46 | 20.9 | 15.22 | 386.6 | 10.5 | 266.7 | No |
| 92RB029 | 7.9 | 5.89 | Yes | 402 | 545 | 327 | 201 | 272.52 | 160 | 280 | 380 | 225 | 6.37 | 78 | 35.4 | 15.22 | 386.6 | 10.5 | 266.7 | No |
| 92RB036 | 7.9 | 5.89 | Yes | 497 | 674 | 264 | 248.5 | 336.92 | 130 | 345 | 468 | 225 | 6.37 | 78 | 35.4 | 15.22 | 386.6 | 10.5 | 266.7 | No |
| 92RB045 | 7.9 | 5.89 | Yes | 626 | 849 | 210 | 313 | 424.37 | 103 | 440 | 597 | 225 | 6.37 | 78 | 35.4 | 15.22 | 386.6 | 10.5 | 266.7 | No |
| 92RB078 | 7.9 | 5.89 | Yes | 1090 | 1478 | 120 | 545 | 738.92 | 59 |
