人体工程学设计
卵型外壳设计经过优化，手感自然，操作员舒适度好。
用户体验好
这款微型电动螺丝刀采用紧凑、良好平衡的轻量设计，处处为您考虑周到。
安全性好
静电释放 (ESD) 安全
| Model | Actuation | Voltage | Torque Range (Nm) | Torque Range (in-lbs) | Free Speed (rpm) | Weight (kg) | Weight (lb.) | Length (mm) | Length (in) | Spindle Type | Controller Required | Controller Input Voltage | Controller Output Voltage | Controller Weight (kg) | Controller Weight (lbs) | Controller Dimensions L x W x H (mm) | Controller Dimensions L x W x H (in) | Controller Soft Start | Controller Speed Adjustment | ESD Control |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ELM0107N | Inline - Lever Start | 24 V DC | 0.02 - 0.20 | 0.18 - 1.77 | 750 | 0.23 | 0.51 | 166 | 6.52 | 0.16 in. | ECM24N | 115 V AC | 24 V DC | 0.9 | 1.98 | 150 x 91 x 52 | 5.9 x 3.6 x 2.1 | Yes | Yes | Yes |
| ELM0110N | Inline - Lever Start | 24 V DC | 0.02 - 0.20 | 0.18 - 1.77 | 1000 | 0.23 | 0.51 | 166 | 6.52 | 0.16 in. | ECM24N | 115 V AC | 24 V DC | 0.9 | 1.98 | 150 x 91 x 52 | 5.9 x 3.6 x 2.1 | Yes | Yes | Yes |
| ELM0306N | Inline - Lever Start | 24 V DC | 0.15 - 0.40 | 1.33 - 3.54 | 600 | 0.23 | 0.51 | 166 | 6.52 | 0.16 in. | ECM24N | 115 V AC | 24 V DC | 0.9 | 1.98 | 150 x 91 x 52 | 5.9 x 3.6 x 2.1 | Yes | Yes | Yes |
