安全性好
符合 ATEX 标准
耐用性好
即使是在恶劣的环境中，2200 系列也能充当您坚实的后盾。适合侧面负载很高的应用，例如铣锯加工。
保养简便
由于能够快速修复工具，因此您能够将更多时间用在本职工作中。
<table>
<thead>
<tr>
<th>Model</th>
<th>Max. Power (hp)</th>
<th>Max. Power (kw)</th>
<th>Reversible</th>
<th>Torque Stall (ft-lb)</th>
<th>Torque Stall (Nm)</th>
<th>Free Speed (rpm)</th>
<th>Torque Output @ Max. H.P. (ft-lb)</th>
<th>Torque Output @ Max. H.P. (Nm)</th>
<th>Speed at Max. Power (rpm)</th>
<th>Spindle</th>
<th>Air Consumption at Max. Power (scfm)</th>
<th>Air Consumption at Max. Power (m^3/m)</th>
<th>Air Consumption @ Free Speed (scfm)</th>
<th>Air Consumption @ Free Speed (L/s)</th>
<th>Sound Level @ Free Speed dB(A)</th>
<th>Weight (lb)</th>
<th>Weight (kg)</th>
<th>Length (in)</th>
<th>Length (mm)</th>
<th>Diameter/Width (in)</th>
<th>Diameter/Width (mm)</th>
<th>Gear Reduction</th>
<th>In Line Motor</th>
</tr>
</thead>
<tbody>
<tr>
<td>7800-2B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>1</td>
<td>1.4</td>
<td>18000</td>
<td>0.5</td>
<td>0.68</td>
<td>9000</td>
<td>3/8 in. Maxiumum Collet Capacity</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>4.89</td>
<td>2.2</td>
<td>8.34</td>
<td>211.9</td>
<td>3.5</td>
<td>88.9</td>
<td>Single</td>
<td>Yes</td>
</tr>
<tr>
<td>7800-4B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>1</td>
<td>1.4</td>
<td>18000</td>
<td>0.5</td>
<td>0.68</td>
<td>9000</td>
<td>3/8 in. Maxiumum Collet Capacity</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>4.89</td>
<td>2.2</td>
<td>8.38</td>
<td>212.7</td>
<td>3.56</td>
<td>90.4</td>
<td>Single</td>
<td>Yes</td>
</tr>
<tr>
<td>7801-2B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>4</td>
<td>5.5</td>
<td>4600</td>
<td>2</td>
<td>2.5</td>
<td>2300</td>
<td>3/8 in. Maxiumum Collet Capacity</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>4.89</td>
<td>2.2</td>
<td>8.34</td>
<td>211.9</td>
<td>3.5</td>
<td>88.9</td>
<td>Single</td>
<td>Yes</td>
</tr>
<tr>
<td>7801-3B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>4</td>
<td>5.5</td>
<td>4600</td>
<td>2</td>
<td>2.5</td>
<td>2300</td>
<td>7/16 in. -20 UNF-3A Threaded</td>
<td>Plus 1/8 in. Sq. Key Drive</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>4.89</td>
<td>2.2</td>
<td>9.5</td>
<td>241.3</td>
<td>3.5</td>
<td>88.9</td>
<td>Single</td>
</tr>
<tr>
<td>7801-4B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>4</td>
<td>5.5</td>
<td>4600</td>
<td>2</td>
<td>2.5</td>
<td>2300</td>
<td>3/8 in. Maxiumum Collet Capacity</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>4.89</td>
<td>2.2</td>
<td>8.38</td>
<td>212.7</td>
<td>3.56</td>
<td>90.4</td>
<td>Single</td>
<td>Yes</td>
</tr>
<tr>
<td>7802-2B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>7.5</td>
<td>10.3</td>
<td>2500</td>
<td>3.75</td>
<td>4.7</td>
<td>1250</td>
<td>3/8 in. Maxiumum Collet Capacity</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>4.89</td>
<td>2.2</td>
<td>8.34</td>
<td>211.9</td>
<td>3.5</td>
<td>88.9</td>
<td>Single</td>
<td>Yes</td>
</tr>
<tr>
<td>7802-4B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>7.5</td>
<td>10.3</td>
<td>2500</td>
<td>3.75</td>
<td>4.7</td>
<td>1250</td>
<td>3/8 in. Maxiumum Collet Capacity</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>4.89</td>
<td>2.2</td>
<td>8.38</td>
<td>212.7</td>
<td>3.56</td>
<td>90.4</td>
<td>Single</td>
<td>Yes</td>
</tr>
<tr>
<td>7803-2B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>16</td>
<td>21.9</td>
<td>1200</td>
<td>8</td>
<td>10.2</td>
<td>600</td>
<td>3/8 in. Maxiumum Collet Capacity</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>6.39</td>
<td>2.86</td>
<td>10.06</td>
<td>255.5</td>
<td>3.5</td>
<td>88.9</td>
<td>Double</td>
<td>Yes</td>
</tr>
<tr>
<td>7803-3B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>16</td>
<td>21.9</td>
<td>1200</td>
<td>8</td>
<td>10.2</td>
<td>600</td>
<td>7/16 in. -20 UNF-3A Threaded</td>
<td>Plus 1/8 in. Sq. Key Drive</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>6.39</td>
<td>2.86</td>
<td>11.28</td>
<td>286.5</td>
<td>3.5</td>
<td>88.9</td>
<td>Double</td>
</tr>
<tr>
<td>7803-4B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>16</td>
<td>21.9</td>
<td>1200</td>
<td>8</td>
<td>10.2</td>
<td>600</td>
<td>3/8 in. Maxiumum Collet Capacity</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>6.39</td>
<td>2.86</td>
<td>10.19</td>
<td>258.8</td>
<td>3.56</td>
<td>90.4</td>
<td>Double</td>
<td>Yes</td>
</tr>
<tr>
<td>7804-2B</td>
<td>0.85</td>
<td>0.63</td>
<td>No</td>
<td>30</td>
<td>41.2</td>
<td>650</td>
<td>15</td>
<td>19.1</td>
<td>325</td>
<td>3/8 in. Maxiumum Collet Capacity</td>
<td>41.7</td>
<td>1.18</td>
<td>41.7</td>
<td>19.7</td>
<td>78</td>
<td>6.39</td>
<td>2.86</td>
<td>10.06</td>
<td>255.5</td>
<td>3.5</td>
<td>88.9</td>
<td>Double</td>
<td>Yes</td>
</tr>
</tbody>
</table>
