用户体验好
采用特殊的人机工程学设计外壳，具有可靠的操作员握持表面，功率重量比经过优化，让您能够更快地轻松完成工作。
耐用性好
采用高质量夹头，6 系列弯角钻能够抵御恶劣条件。
性能高
这些钻能够让您在关键应用中精确钻孔，因此，您知道您的工作将圆满完成，完全符合预期。
Model | Actuation | Reversible | Max. Working Torque (Nm) | Max. Working Torque (in-lb) | Free Speed (rpm) | Weight with Chuck (kg) | Weight with Chuck (lb) | Length with Chuck (mm) | Length with Chuck (in) | Bit Holder Capacity (in) | Bit Holder Capacity (mm) | Angle Head Heights w/ Chuck (mm) | Angle Head Heights w/ Chuck (in) | Side to Center (mm) | Side to Center (in) | Sound Level dB(A) | Rated Power (hp) | Head Style | Air Inlet | cfm |
6LH1A1 | Lever Start | No | 6000 | 0.95 | 2.13 | 246 | 9.69 | 1/4 in.- 28 Female Thread | N/A | 0.51 | 90 Degree Small Head | 1/4 in. NPT | 20 | |||||||
6LJ1A1 | Lever Start | No | 5100 | 0.95 | 2.13 | 246 | 9.69 | 1/4 in.- 28 Female Thread | N/A | 0.51 | 90 Degree Small Head | 1/4 in. NPT | 20 | |||||||
6LJJ1A1 | Lever Start | No | 3950 | 0.95 | 2.13 | 246 | 9.69 | 1/4 in.- 28 Female Thread | N/A | 0.51 | 90 Degree Small Head | 1/4 in. NPT | 20 | |||||||
6LK1A1 | Lever Start | No | 3100 | 0.95 | 2.13 | 246 | 9.69 | 1/4 in.- 28 Female Thread | N/A | 0.51 | 90 Degree Small Head | 1/4 in. NPT | 20 | |||||||
6LK2A41 | Lever Start | No | 7.3 | 64.6 | 2000 | 1.3 | 2.8 | 241 | 9.5 | 1/4 | 6 | 75 | 3 | 14 | 0.5 | 74 | 0.51 | 90 Degree Chuck | 1/4 in. NPT | 20 |
6LR3A44 | Lever Start | No | 36.2 | 320.4 | 400 | 1.8 | 4 | 272 | 10.7 | 1/2 | 13 | 105 | 4.1 | 18 | 0.7 | 74 | 0.51 | 90 Degree Chuck | 1/4 in. NPT | 20 |
