安全性好
符合 ATEX 标准
耐用性好
3800 系列能够承受恶劣的环境，并保持正常运行。
性能高
借助可变速度和扭矩以及即时起动和反转功能，您将能够轻松地完成自己的工作。
保养简便
保养简便的 3800 系列将可杜绝长时间进行维修的现象，从而提高生产率。
| Model | Max. Power (hp) | Max. Power (kw) | Reversible | Torque Stall (ft-lb) | Torque Stall (Nm) | Free Speed (rpm) | Torque Output @ Max. H.P. (ft-lb) | Torque Output @ Max. H.P. (Nm) | Speed at Max. Power (rpm) | Starting Torque (ft-lb) | Starting Torque (Nm) | Air Consumption at Max. Power (scfm) | Air Consumption at Max. Power (m^3/m) | Weight (lb) | Weight (kg) | Length (in) | Length (mm) | Diameter/Width (in) | Diameter/Width (mm) | In Line Motor |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3800M | 1.55 | 1.16 | No | 33 | 44.8 | 1100 | 16.5 | 22.37 | 550 | 24 | 32.5 | 48 | 1.36 | 7.125 | 3.23 | 7 | 177.8 | 3.63 | 92.2 | Yes |
| 3800P | 1.45 | 1.08 | No | 56.5 | 76.6 | 600 | 28.25 | 38.3 | 300 | 42 | 57 | 48 | 1.36 | 8.5 | 3.86 | 7 | 177.8 | 3.63 | 92.2 | Yes |
| 3800Q | 1.45 | 1.08 | No | 83.5 | 113 | 375 | 41.75 | 56.61 | 187.5 | 62 | 84 | 48 | 1.36 | 8.5 | 3.86 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
| 3800R | 1.45 | 1.08 | No | 96 | 130 | 320 | 48 | 65.08 | 160 | 72 | 98 | 48 | 1.36 | 8.5 | 3.86 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
| 3800S | 1.45 | 1.08 | No | 118 | 160 | 255 | 59 | 80 | 127.5 | 88 | 119 | 48 | 1.36 | 8.5 | 3.86 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
| 3800U | 1.45 | 1.08 | No | 140 | 189 | 220 | 70 | 94.91 | 110 | 105 | 142 | 48 | 1.36 | 8.5 | 3.86 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
| 3840M | 1.4 | 1.04 | Yes | 31.5 | 42.7 | 825 | 15.75 | 21.35 | 412.5 | 23 | 31.2 | 44 | 1.25 | 7.375 | 3.35 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
| 3840P | 1.35 | 1.01 | Yes | 53.5 | 72.6 | 440 | 26.75 | 36.27 | 220 | 40 | 54.2 | 44 | 1.25 | 8.75 | 3.97 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
| 3840Q | 1.35 | 1.01 | Yes | 80 | 106 | 280 | 40 | 54.23 | 140 | 60 | 81.4 | 44 | 1.25 | 8.75 | 3.97 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
| 3840R | 1.35 | 1.01 | Yes | 92 | 125 | 238 | 46 | 62.37 | 119 | 69 | 93 | 44 | 1.25 | 8.75 | 3.97 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
| 3840S | 1.35 | 1.01 | Yes | 115 | 156 | 190 | 57.5 | 77.96 | 95 | 86 | 116 | 44 | 1.25 | 8.75 | 3.97 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
| 3840U | 1.35 | 1.01 | Yes | 134 | 181 | 162 | 67 | 90.84 | 81 | 100 | 135 | 44 | 1.25 | 8.75 | 3.97 | 8.69 | 220.7 | 3.63 | 92.2 | Yes |
