QE4 弯角

准确
闭环转换控制提供优异的精确度和可追溯性，实现高级扭矩控制策略。

生产率
QE4 弯角系列随附众多功能，其设计专门用于增强用户体验，使您能够始终专注于手头的任务而不分心，从而连续工作、不减速。

高度可配置平台
该系列工具能够改变输出扭矩、机身风格、动作和拧紧轴类型，让您能够拥有每一个应用需要的准确功能。

可靠性高
配备无刷直流电机、非接触式开关和重型齿轮传动机构，该系列可靠性好、效率高。具有预防性维护提醒和高温电机保护功能，您无需担心您的工具在工作中途出故障。

安全性好
符合 ESD-Safe 和 RoHS

<table>

<thead>

<tr>

<th>Model</th>

<th>Torque Range (Nm)</th>

<th>Torque Range (in-lbs)</th>

<th>Torque Range (ft-lbs)</th>

<th>Max Torque (Nm)</th>

<th>Actuation</th>

<th>Configuration</th>

<th>Free Speed (rpm)</th>

<th>Spindle Length (mm)</th>

<th>Float (mm)</th>

<th>Overall Length (mm)</th>

<th>Length (in)</th>

<th>Weight (kg)</th>

<th>Weight (lbs)</th>

<th>Drive (size/style)</th>

</tr>

</thead>

<tbody>

<tr>

<td>QE4AT013PA2H04</td>

<td>2.6 - 10.4</td>

<td>23.0 - 92.1</td>

<td>1.9-7.7</td>

<td>13</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>1200</td>

<td>N/A</td>

<td>N/A</td>

<td>383</td>

<td>15.078740157480317</td>

<td>1.3</td>

<td>2.87</td>

<td>1/4 in. Hex Detent</td>

</tr>

<tr>

<td>QE4AT013PA2Q04</td>

<td>2.6 - 10.4</td>

<td>23.0 - 92.1</td>

<td>1.9-7.7</td>

<td>13</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>1200</td>

<td>N/A</td>

<td>N/A</td>

<td>383</td>

<td>15.078740157480317</td>

<td>1.3</td>

<td>2.87</td>

<td>1/4 in. Quick Change</td>

</tr>

<tr>

<td>QE4AT013PA2S04</td>

<td>2.6 - 10.4</td>

<td>23.0 - 92.1</td>

<td>1.9-7.7</td>

<td>13</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>1200</td>

<td>N/A</td>

<td>N/A</td>

<td>383</td>

<td>15.078740157480317</td>

<td>1.3</td>

<td>2.87</td>

<td>1/4 in. Square</td>

</tr>

<tr>

<td>QE4AT013PA2S06</td>

<td>2.6 - 10.4</td>

<td>23.0 - 92.1</td>

<td>1.9-7.7</td>

<td>13</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>1200</td>

<td>N/A</td>

<td>N/A</td>

<td>383</td>

<td>15.078740157480317</td>

<td>1.3</td>

<td>2.87</td>

<td>3/8 in. Square</td>

</tr>

<tr>

<td>QE4AT020PA2H04</td>

<td>4.0 - 16.0</td>

<td>35.4 - 141.61</td>

<td>3.0 - 11.8</td>

<td>20</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>820</td>

<td>N/A</td>

<td>N/A</td>

<td>383</td>

<td>15.078740157480317</td>

<td>1.3</td>

<td>2.87</td>

<td>1/4 in. Hex Detent</td>

</tr>

<tr>

<td>QE4AT020PA2Q04</td>

<td>4.0 - 16.0</td>

<td>35.4 - 141.61</td>

<td>3.0 - 11.8</td>

<td>20</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>820</td>

<td>N/A</td>

<td>N/A</td>

<td>383</td>

<td>15.078740157480317</td>

<td>1.3</td>

<td>2.87</td>

<td>1/4 in. Quick Change</td>

</tr>

<tr>

<td>QE4AT020PA2S04</td>

<td>4.0 - 16.0</td>

<td>35.4 - 141.61</td>

<td>3.0 - 11.8</td>

<td>20</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>820</td>

<td>N/A</td>

<td>N/A</td>

<td>383</td>

<td>15.078740157480317</td>

<td>1.3</td>

<td>2.87</td>

<td>1/4 in. Square</td>

</tr>

<tr>

<td>QE4AT020PA2S06</td>

<td>4.0 - 16.0</td>

<td>35.4 - 141.61</td>

<td>3.0 - 11.8</td>

<td>20</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>820</td>

<td>N/A</td>

<td>N/A</td>

<td>383</td>

<td>15.078740157480317</td>

<td>1.3</td>

<td>2.87</td>

<td>3/8 in. Square</td>

</tr>

<tr>

<td>QE4AT027PA4S06</td>

<td>5.4 - 21.6</td>

<td>47.8 - 191.2</td>

<td>4.0 - 15.9</td>

<td>27</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>600</td>

<td>N/A</td>

<td>N/A</td>

<td>387</td>

<td>15.236220472440946</td>

<td>1.3</td>

<td>2.87</td>

<td>3/8 in. Square</td>

</tr>

<tr>

<td>QE4AT027PA4S08</td>

<td>5.4 - 21.6</td>

<td>47.8 - 191.2</td>

<td>4.0 - 15.9</td>

<td>27</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>600</td>

<td>N/A</td>

<td>N/A</td>

<td>387</td>

<td>15.236220472440946</td>

<td>1.3</td>

<td>2.87</td>

<td>1/2 in. Square</td>

</tr>

<tr>

<td>QE4AT034PA4S06</td>

<td>6.8 - 27.2</td>

<td>60.2 - 240.7</td>

<td>5.0 - 20.1</td>

<td>34</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>470</td>

<td>N/A</td>

<td>N/A</td>

<td>387</td>

<td>15.236220472440946</td>

<td>1.3</td>

<td>2.87</td>

<td>3/8 in. Square</td>

</tr>

<tr>

<td>QE4AT034PA4S08</td>

<td>6.8 - 27.2</td>

<td>60.2 - 240.7</td>

<td>5.0 - 20.1</td>

<td>34</td>

<td>Trigger Start</td>

<td>Angle</td>

<td>470</td>

<td>N/A</td>

<td>N/A</td>

<td>387</td>

<td>15.236220472440946</td>

<td>1.3</td>

<td>2.87</td>

<td>1/2 in. Square</td>

</tr>

</tbody>

</table>
