QE2 电机-英格索兰动力工具 Ingersoll Rand Power Tools中国官网

这些尺寸紧凑、重量轻、速度高的电机转速可达 3,000 rpms，扭矩范围达 0.3 Nm 至 400 Nm。非常适合任何拧紧作业。

准确
闭环转换控制提供优异的精确度和可追溯性，实现高级扭矩控制策略。

专为您制造
QE2 电机的设计以用户体验为中心。配备 LED 前灯和 TactAlert，具有多灯配置，项目工作从未如此轻松。

高度可配置
该系列功能多样，让您能够为每次使用定制输出扭矩、机身风格、动作和拧紧轴类型。

值得信赖
Ingersoll Rand 创造您可以信赖的工具，该系列采用非接触式开关、重型齿轮传动机构和无刷直流电机，让事实说话。

安全性好
符合 ESD-Safe 和 RoHS

Model	Torque Range (Nm)	Torque Range (in-lbs)	Torque Range (ft-lbs)	Max Torque (Nm)	Actuation	Configuration	Free Speed (rpm)	Spindle Length (mm)	Float (mm)	Overall Length (mm)	Length (in)	Weight (kg)	Weight (lbs)	Drive (size/style)
QE2PP002PM0	0.3 - 1.5	2.7 - 13.3	0.2-1.1	2	Trigger + Push-to-Start	Pistol	3000	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PP003PM0	0.6 - 3.0	5.3 - 26.6	0.4-2.2	3	Trigger + Push-to-Start	Pistol	2450	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PP005PM0	1.0 - 5.0	8.9 - 44.3	0.7-3.7	5	Trigger + Push-to-Start	Pistol	1700	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PP007PM0	1.3 - 6.5	11.5 - 57.5	1.0-4.8	7	Trigger + Push-to-Start	Pistol	1250	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PP010PM0	2.0 - 10.0	17.7 - 88.5	1.5-7.4	10	Trigger + Push-to-Start	Pistol	850	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PS002PM0	0.3 - 1.5	2.7 - 13.3	0.2-1.1	2	Push-to-Start	Pistol	3000	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PS003PM0	0.6 - 3.0	5.3 - 26.6	0.4-2.2	3	Push-to-Start	Pistol	2450	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PS005PM0	1.0 - 5.0	8.9 - 44.3	0.7-3.7	5	Push-to-Start	Pistol	1700	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PS007PM0	1.3 - 6.5	11.5 - 57.5	1.0-4.8	7	Push-to-Start	Pistol	1250	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PS010PM0	2.0 - 10.0	17.7 - 88.5	1.5-7.4	10	Push-to-Start	Pistol	850	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PT002PM0	0.3 - 1.5	2.7 - 13.3	0.2-1.1	2	Trigger Start	Pistol	3000	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PT003PM0	0.6 - 3.0	5.3 - 26.6	0.4-2.2	3	Trigger Start	Pistol	2450	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PT005PM0	1.0 - 5.0	8.9 - 44.3	0.7-3.7	5	Trigger Start	Pistol	1700	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PT007PM0	1.3 - 6.5	11.5 - 57.5	1.0-4.8	7	Trigger Start	Pistol	1250	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2PT010PM0	2.0 - 10.0	17.7 - 88.5	1.5-7.4	10	Trigger Start	Pistol	850	N/A	N/A	248.7	9.791338582677165	0.72	1.59	N/A
QE2SL002PM0	0.3 - 1.5	2.7 - 13.3	0.2-1.1	2	Lever Start	Inline	3000	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2SL003PM0	0.6 - 3.0	5.3 - 26.6	0.4-2.2	3	Lever Start	Inline	2450	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2SL005PM0	1.0 - 5.0	8.9 - 44.3	0.7-3.7	5	Lever Start	Inline	1700	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2SL007PM0	1.3 - 6.5	11.5 - 57.5	1.0-4.8	7	Lever Start	Inline	1250	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2SL010PM0	2.0 - 10.0	17.7 - 88.5	1.5-7.4	10	Lever Start	Inline	850	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2SP002PM0	0.3 - 1.5	2.7 - 13.3	0.2-1.1	2	Lever + Push-to-Start	Inline	3000	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2SP003PM0	0.6 - 3.0	5.3 - 26.6	0.4-2.2	3	Lever + Push-to-Start	Inline	2450	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2SP005PM0	1.0 - 5.0	8.9 - 44.3	0.7-3.7	5	Lever + Push-to-Start	Inline	1700	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2SP007PM0	1.3 - 6.5	11.5 - 57.5	1.0-4.8	7	Lever + Push-to-Start	Inline	1250	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2SP010PM0	2.0 - 10.0	17.7 - 88.5	1.5-7.4	10	Lever + Push-to-Start	Inline	850	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2TS002PM0	0.3 - 1.5	2.7 - 13.3	0.2-1.1	2	Push-to-Start	Inline	3000	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2TS003PM0	0.6 - 3.0	5.3 - 26.6	0.4-2.2	3	Push-to-Start	Inline	2450	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2TS005PM0	1.0 - 5.0	8.9 - 44.3	0.7-3.7	5	Push-to-Start	Inline	1700	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2TS007PM0	1.3 - 6.5	11.5 - 57.5	1.0-4.8	7	Push-to-Start	Inline	1250	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
QE2TS010PM0	2.0 - 10.0	17.7 - 88.5	1.5-7.4	10	Push-to-Start	Inline	850	N/A	N/A	250	9.84251968503937	0.67	1.52	N/A
